Category

Item

Specification

X-ray System

Tube Type

Closed micro-focus X-ray tube

Tube Voltage

90 kV

Tube Current

10–200 μA

Focus Size

5 μm

Geometric Magnification

150× (1500× system magnification)

Cooling Method

Air-cooled

Detector

Type

Digital HD flat panel

Pixel Matrix

1536×1536

Pixel Spacing

85 μm

Image Frame Rate

20 fps (1×1)

Stage & Motion

Load Capacity

10 kg

Travel Range (X/Y)

350×300 mm

Travel Range (Z 1&2)

380 mm

Safety

Radiation Dose

<1 μSv/h

Exemption Certification

Yes (YFHB No. [20200072])

Power

Total Power

1400 W / 8W (X-ray only)

Supply Voltage

110–220V, 50/60 Hz

Dimensions & Weight

Equipment Size

1005×930×1660 mm

Weight

834 kg
